01 1595 00

01 1595 00 Four Point Contact Ball Slewing Ring Bearing
Part Number 01 1595 00
Brand: LILY
|
Equivalent: ROLLIX
System of Measurement Metric
Series rectangular sections
Gear External Gear
Type Ball
Bearing Type Standard
Product Type Slewing Beraing
Inside Diameter Of Inner Ring 1500 mm
Outside Diameter Of Outer Ring 1727 mm
Height Of Overall Bearing Assembly 63 mm
Height Of Inner Ring 54 mm
Height Of Outer Ring 54 mm
Bolt Circle In Inner Ring 1536 mm
Bolt Circle In Outer Ring 1654 mm
Size Holes In Inner Ring ref. Drawing
Size Holes In Outer Ring ref. Drawing
Number Holes In Inner Ring 24
Number Holes In Outer Ring 24
Pitch Diameter Of Gear 1712 mm
Module 8
Number Of Gear Teeth 214
Tooth Form Droite
Ring Material 42CRO or 50MN
Ball Materrial Chrome Steel
Cage Material Nylon or 300 Series Stainless Steel
Seal Material NBR
RoHS Compliant
Weight 213 Kg

Request a Quote

*
*
*
Allow file formats (gif、jpeg、jpg、png、pdf、txt、doc、xls、xlsx、docx)
INTERCHANGE
The LILY bearing part series 01 1595 00 is a potential replacement for these common bearing part numbers.
LILY
ROLLIX
L01 1595 00
01 1595 00
