01 2040 03 Four Point Contact Ball Slewing Ring Bearing
Part Number 01 2040 03
Brand: LILY
|
Equivalent: ROLLIX
System of Measurement Metric
Series rectangular sections
Gear External Gear
Type Ball
Bearing Type Standard
Product Type Slewing Beraing
Inside Diameter Of Inner Ring 1950 mm
Outside Diameter Of Outer Ring 2165 mm
Height Of Overall Bearing Assembly 68 mm
Height Of Inner Ring 59 mm
Height Of Outer Ring 59 mm
Bolt Circle In Inner Ring 1985 mm
Bolt Circle In Outer Ring 2090 mm
Size Holes In Inner Ring ref. Drawing
Size Holes In Outer Ring ref. Drawing
Number Holes In Inner Ring 36
Number Holes In Outer Ring 36
Pitch Diameter Of Gear 2149.5 mm
Module 8
Number Of Gear Teeth 269
Tooth Form Droite
Ring Material 42CRO or 50MN
Ball Materrial Chrome Steel
Cage Material Nylon or 300 Series Stainless Steel
Seal Material NBR
RoHS Compliant
Weight 278 Kg

Request a Quote

*
*
*
Allow file formats (gif、jpeg、jpg、png、pdf、txt、doc、xls、xlsx、docx)
INTERCHANGE
The LILY bearing part series 01 2040 03 is a potential replacement for these common bearing part numbers.
LILY
ROLLIX
L01 2040 03
01 2040 03
