01 2130 00
Part Number | 01 2130 00 |
Brand: LILY | |
Equivalent: ROLLIX |
System of Measurement | Metric |
Series | rectangular sections |
Gear | External Gear |
Type | Ball |
Bearing Type | Standard |
Product Type | Slewing Beraing |
Inside Diameter Of Inner Ring | 76.772" |
Outside Diameter Of Outer Ring | 94.094" |
Height Of Overall Bearing Assembly | 5.118" |
Height Of Inner Ring | 4.331" |
Height Of Outer Ring | 4.724" |
Bolt Circle In Inner Ring | 79.724" |
Bolt Circle In Outer Ring | 87.992" |
Size Holes In Inner Ring | ref. Drawing |
Size Holes In Outer Ring | ref. Drawing |
Number Holes In Inner Ring | 60 |
Number Holes In Outer Ring | 60 |
Pitch Diameter Of Gear | 92.835" |
Module | 18 |
Number Of Gear Teeth | 130 |
Tooth Form | Droite |
Ring Material | 42CRO or 50MN |
Ball Materrial | Chrome Steel |
Cage Material | Nylon or 300 Series Stainless Steel |
Seal Material | NBR |
RoHS | Compliant |
Weight | 1111 Kg |
INTERCHANGE
The LILY bearing part series 01 2130 00 is a potential replacement for these common bearing part numbers.
LILY
ROLLIX
L01 2130 00
01 2130 00
