02 0720 02
Part Number | 02 0720 02 |
Brand: LILY | |
Equivalent: ROLLIX |
System of Measurement | Metric |
Series | rectangular sections |
Gear | Internal Gear |
Type | Ball |
Bearing Type | Standard |
Product Type | Slewing Beraing |
Inside Diameter Of Inner Ring | 22.756" |
Outside Diameter Of Outer Ring | 32.874" |
Height Of Overall Bearing Assembly | 3.228" |
Height Of Inner Ring | 2.835" |
Height Of Outer Ring | 2.598" |
Bolt Circle In Inner Ring | 25.748" |
Bolt Circle In Outer Ring | 30.945" |
Size Holes In Inner Ring | ref. Drawing |
Size Holes In Outer Ring | ref. Drawing |
Number Holes In Inner Ring | 30 |
Number Holes In Outer Ring | 30 |
Pitch Diameter Of Gear | 23.307" |
Module | 8 |
Number Of Gear Teeth | 73 |
Tooth Form | Droite |
Ring Material | 42CRO or 50MN |
Ball Materrial | Chrome Steel |
Cage Material | Nylon or 300 Series Stainless Steel |
Seal Material | NBR |
RoHS | Compliant |
Weight | 130 Kg |
INTERCHANGE
The LILY bearing part series 02 0720 02 is a potential replacement for these common bearing part numbers.
LILY
ROLLIX
L02 0720 02
02 0720 02
