03 0600 02

03 0600 02 Four Point Contact Ball Slewing Ring Bearing
Part Number 03 0600 02
Brand: LILY
|
Equivalent: ROLLIX
System of Measurement Metric
Series rectangular sections
Gear Without Gear
Type Ball
Bearing Type Standard
Product Type Slewing Beraing
Inside Diameter Of Inner Ring 487 mm
Outside Diameter Of Outer Ring 712 mm
Height Of Overall Bearing Assembly 72 mm
Height Of Inner Ring 63 mm
Height Of Outer Ring 63 mm
Bolt Circle In Inner Ring 531 mm
Bolt Circle In Outer Ring 668 mm
Size Holes In Inner Ring ref. Drawing
Size Holes In Outer Ring ref. Drawing
Number Holes In Inner Ring 24
Number Holes In Outer Ring 24
Ring Material 42CRO or 50MN
Ball Materrial Chrome Steel
Cage Material Nylon or 300 Series Stainless Steel
Seal Material NBR
RoHS Compliant
Weight 91 Kg

Request a Quote

*
*
*
Allow file formats (gif、jpeg、jpg、png、pdf、txt、doc、xls、xlsx、docx)
INTERCHANGE
The LILY bearing part series 03 0600 02 is a potential replacement for these common bearing part numbers.
LILY
ROLLIX
L03 0600 02
03 0600 02
