06 0307 00
| Part Number | 06 0307 00 |
Brand: LILY  | |
Equivalent: ROLLIX |
| System of Measurement | Metric |
| Series | cross roller |
| Gear | External Gear |
| Type | Roller |
| Bearing Type | Standard |
| Product Type | Slewing Beraing |
| Inside Diameter Of Inner Ring | 234 mm |
| Outside Diameter Of Outer Ring | 403.5 mm |
| Height Of Overall Bearing Assembly | 55 mm |
| Height Of Inner Ring | 45 mm |
| Height Of Outer Ring | 47 mm |
| Bolt Circle In Inner Ring | 259 mm |
| Bolt Circle In Outer Ring | 358 mm |
| Size Holes In Inner Ring | ref. Drawing |
| Size Holes In Outer Ring | ref. Drawing |
| Number Holes In Inner Ring | 28 |
| Number Holes In Outer Ring | 24 |
| Pitch Diameter Of Gear | 396 mm |
| Module | 4.5 |
| Number Of Gear Teeth | 88 |
| Tooth Form | Droite |
| Ring Material | 42CRO or 50MN |
| Ball Materrial | Chrome Steel |
| Cage Material | Nylon or 300 Series Stainless Steel |
| Seal Material | NBR |
| RoHS | Compliant |
| Weight | 25 Kg |
})
INTERCHANGE
The LILY bearing part series 06 0307 00 is a potential replacement for these common bearing part numbers.
LILY
ROLLIX
L06 0307 00
06 0307 00
