192.32.2240.990.41.1502
| Part Number | 192.32.2240.990.41.1502 |
Brand: LILY  | |
Equivalent: ROTHEERDE |
| System of Measurement | Metric |
| Series | Series 19 |
| Gear | Internal Gear |
| Type | Roller |
| Bearing Type | Standard |
| Product Type | Slewing Beraing |
| Inside Diameter Of Inner Ring | 1908 mm |
| Outside Diameter Of Outer Ring | 2210 mm |
| Internal Diameter On Outer Ring | 2458 mm |
| External Diameter On Inner Ring | 219 mm |
| Height Of Overall Bearing Assembly | 181 mm |
| Height Of Inner Ring | 172 mm |
| Height Of Outer Ring | 139 mm |
| Bolt Size | 36 mm |
| Bolt Circle In Inner Ring | 2085 mm |
| Bolt Circle In Outer Ring | 2380 mm |
| Size Holes In Inner Ring | 39 mm |
| Size Holes In Outer Ring | 39 mm |
| Number Holes In Inner Ring | 40 |
| Number Holes In Outer Ring | 40 |
| Pitch Diameter Of Gear | 1926 mm |
| Module | 18 |
| Number Of Gear Teeth | 107 |
| Permissible Tooth Forces T | 48960 lbs |
| Max Gear Tooth Load Fz | 97920 lbs |
| Correspond | FIG2 |
| Tooth Width | 139 mm |
| Ring Material | 42CRO or 50MN |
| Ball Materrial | Chrome Steel |
| Cage Material | Nylon or 300 Series Stainless Steel |
| Seal Material | NBR |
| RoHS | Compliant |
| Weight | 2010 Kg |
| Diameter Of Bearing Raceway | 2240 mm |
| Distance Between Bottom Outer Ring/Inner Ring | 9 mm |
| Distance at top Outer Ring/Inner Ring | 42 mm |
| Number Of Grease Nipples | 8 |
})
INTERCHANGE
The LILY bearing part series 192.32.2240.990.41.1502 is a potential replacement for these common bearing part numbers.
LILY
ROTHEERDE
L192.32.2240.990.41.1502
192.32.2240.990.41.1502
