27 0641 01
| Part Number | 27 0641 01 |
Brand: LILY  | |
Equivalent: ROLLIX |
| System of Measurement | Metric |
| Series | light profile |
| Gear | External Gear |
| Type | Ball |
| Bearing Type | Flanged |
| Product Type | Slewing Beraing |
| Inside Diameter Of Inner Ring | 21.024" |
| Outside Diameter Of Outer Ring | 29.213" |
| Internal Diameter On Inner Ring | 23.543" |
| Height Of Overall Bearing Assembly | 2.205" |
| Height Of Inner Ring | 1.811" |
| Height Of Outer Ring | 1.811" |
| Bolt Circle In Inner Ring | 22.126" |
| Bolt Circle In Outer Ring | 26.969" |
| Size Holes In Inner Ring | ref. Drawing |
| Size Holes In Outer Ring | ref. Drawing |
| Number Holes In Inner Ring | 16 |
| Number Holes In Outer Ring | 16 |
| Pitch Diameter Of Gear | 28.819" |
| Module | 6 |
| Number Of Gear Teeth | 122 |
| Tooth Form | Droite |
| Ring Material | 42CRO or 50MN |
| Ball Materrial | Chrome Steel |
| Cage Material | Nylon or 300 Series Stainless Steel |
| Seal Material | NBR |
| RoHS | Compliant |
| Weight | 52 Kg |
})
INTERCHANGE
The LILY bearing part series 27 0641 01 is a potential replacement for these common bearing part numbers.
LILY
ROLLIX
L27 0641 01
27 0641 01
