29 1091 01 Four Point Contact Ball Slewing Ring Bearing
Part Number 29 1091 01
Brand: LILY
|
Equivalent: ROLLIX
System of Measurement Metric
Series light profile
Gear Without Gear
Type Ball
Bearing Type Flanged
Product Type Slewing Beraing
Inside Diameter Of Inner Ring 984 mm
Outside Diameter Of Outer Ring 1198 mm
Internal Diameter On Inner Ring 1048 mm
External Diameter On Outer Ring 1134 mm
Height Of Overall Bearing Assembly 56 mm
Height Of Inner Ring 46 mm
Height Of Outer Ring 46 mm
Bolt Circle In Inner Ring 1012 mm
Bolt Circle In Outer Ring 1170 mm
Size Holes In Inner Ring ref. Drawing
Size Holes In Outer Ring ref. Drawing
Number Holes In Inner Ring 20
Number Holes In Outer Ring 16
Ring Material 42CRO or 50MN
Ball Materrial Chrome Steel
Cage Material Nylon or 300 Series Stainless Steel
Seal Material NBR
RoHS Compliant
Weight 67 Kg

Request a Quote

*
*
*
Allow file formats (gif、jpeg、jpg、png、pdf、txt、doc、xls、xlsx、docx)
INTERCHANGE
The LILY bearing part series 29 1091 01 is a potential replacement for these common bearing part numbers.
LILY
ROLLIX
L29 1091 01
29 1091 01
