33 0411 01
| Part Number | 33 0411 01 |
Brand: LILY  | |
Equivalent: ROLLIX |
| System of Measurement | Metric |
| Series | rectangular sections |
| Gear | Without Gear |
| Type | Ball |
| Bearing Type | Standard |
| Product Type | Slewing Beraing |
| Inside Diameter Of Inner Ring | 13.465" |
| Outside Diameter Of Outer Ring | 19.134" |
| Height Of Overall Bearing Assembly | 2.205" |
| Height Of Inner Ring | 1.811" |
| Height Of Outer Ring | 1.811" |
| Bolt Circle In Inner Ring | 14.488" |
| Bolt Circle In Outer Ring | 18.11" |
| Size Holes In Inner Ring | ref. Drawing |
| Size Holes In Outer Ring | ref. Drawing |
| Number Holes In Inner Ring | 24 |
| Number Holes In Outer Ring | 24 |
| Ring Material | 42CRO or 50MN |
| Ball Materrial | Chrome Steel |
| Cage Material | Nylon or 300 Series Stainless Steel |
| Seal Material | NBR |
| RoHS | Compliant |
| Weight | 29 Kg |
})
INTERCHANGE
The LILY bearing part series 33 0411 01 is a potential replacement for these common bearing part numbers.
LILY
ROLLIX
L33 0411 01
33 0411 01
