33 0541 01

33 0541 01 Four Point Contact Ball Slewing Ring Bearing
Part Number 33 0541 01
Brand: LILY
|
Equivalent: ROLLIX
System of Measurement Metric
Series rectangular sections
Gear Without Gear
Type Ball
Bearing Type Standard
Product Type Slewing Beraing
Inside Diameter Of Inner Ring 472 mm
Outside Diameter Of Outer Ring 616 mm
Height Of Overall Bearing Assembly 56 mm
Height Of Inner Ring 46 mm
Height Of Outer Ring 46 mm
Bolt Circle In Inner Ring 498 mm
Bolt Circle In Outer Ring 590 mm
Size Holes In Inner Ring ref. Drawing
Size Holes In Outer Ring ref. Drawing
Number Holes In Inner Ring 32
Number Holes In Outer Ring 32
Ring Material 42CRO or 50MN
Ball Materrial Chrome Steel
Cage Material Nylon or 300 Series Stainless Steel
Seal Material NBR
RoHS Compliant
Weight 38 Kg

Request a Quote

*
*
*
Allow file formats (gif、jpeg、jpg、png、pdf、txt、doc、xls、xlsx、docx)
INTERCHANGE
The LILY bearing part series 33 0541 01 is a potential replacement for these common bearing part numbers.
LILY
ROLLIX
L33 0541 01
33 0541 01
