32220
| Part Number | 32220 |
| System of Measurement | Metric |
| Roller Bearing Type | Cylindrical |
| Contact Angle | 15.642° |
| Construction | Single Row |
| Seal Type | Open |
| Bore Dia | 100 mm |
| Outer Dia | 180 mm |
| Width | 49 mm |
| Inner Ring Width | 46 mm |
| Outer Ring Width | 39 mm |
| Bearing Material | Bearing Steel |
| Cage Material | Steel cage |
| Cage Design | Sheet metal |
| Dynamic Radial Load | 87675 lbf |
| Static Radial Load | 98916 lbf |
| Max Speed (X1000 rpm) | 3.6 |
| Reference Speed (X1000 rpm) | 3 |
| Lubricant | None |
| Bearing Part | Complete bearing |
| Coating | Without |
| Matched Arrangement | No |
| Arrangement Of Contact Angle (Double-Row Bearing) | Not applicable |
| Locating Feature, Bearing Outer Ring | None |
| Relubrication Feature | Without |
