AHT12V

AHT12V AHT
Price $ 228.20
Part Number AHT12V
System of Measurement Inch
Bore Dia 0.75"
Bore Dia Tolerance -0.0005" to 0"
Outer Dia 1.4375"
Outer Dia Tolerance -0.0005" to 0"
Ball Width 0.75"
Ball Width Tolerance -0.005" to 0"
Race Width 0.593"
Race Width Tolerance -0.005" to 0"
Shoulder Dia 0.92"
Ball Dia 1.187"
Race Chamfered 0.04"
Mis Alignment
Staking groove Data(P) 0.06"
Staking groove Data(R) 0.02"
Staking groove Data(S) 0.03"
Staking groove Data(X) 0.08"
Dynamic Radial Load 45690 lbs
Static Radial Load 37230 lbs
Weight 0.21 lbs
