BBGCTEI
Price $ 0.55
| Part Number | BBGCTEI |
| System of Measurement | Inch |
| Shape | Cap/Plug |
| Type | Plug |
| Drive Style | Square |
| Pressure Class | 150 |
| Connection Type | Pipe |
| Connection Style | Threaded |
| Connection | NPTF Male |
| Pipe Size | 3/4 |
| Length | 5/8" |
| Plug Construction | Solid |
| Maximum Pressure | 150 psi @ 72° F |
| Maximum Steam Pressure | 150 psi @ 360° F |
| Material | Galvanized Steel |
| For Pipe Schedule | 40 |
| For Pipe Material | Galvanized Steel |
| For Flange Class | 150 |
| For Flange Material | Galvanized Steel |
| Specifications Met | SAE J531 |
| Features | Acrylic Thread Sealant |
| RoHS | RoHS 3 (2015/863/EU) compliant with exemption 6(a)-I - Lead as an alloying element in steel |
| REACH | REACH (EC 1907/2006) (06/14/2023, 235 SVHC) Compliant |
| For Use With | Air, Natural Gas, Oil, Steam, Water |
INTERCHANGE
The LILY Bearing part series BBGCTEI is a potential replacement for these common bearing part numbers.
LILY
MCMASTER
BBGCTEI
