CGGCNDHJ
Part Number | CGGCNDHJ |
System of Measurement | Metric |
Gear Type | Spur |
Component | Gear |
Bore Type | Clamping |
Module | 1 |
Pressure Angle | 20° |
Number Of Teeth | 64 |
Gear Pitch Diameter | 64 mm |
OD | 66 mm |
Face Width | 6 mm |
Overall Width | 16 mm |
For Shaft Diameter | 8 mm |
Material | Plastic |
Fabrication | Molded |
Color | White |
Hub Diameter | 19 mm |
Hub Width | 10 mm |
Hub Material | 303 Stainless Steel |
Clamping Screw Thread size | M3 |
Heat Treatment | Tooth Surface Induction Hardening |
Gear Hardness | 45-55HRC |
Gear Accuracy | ANSI-2 AGMA-11 |
RoHs | RoHS 3 (2015/863/EU) Compliant |
REACH | REACH (EC 1907/2006) (01/16/2020, 205 SVHC) Compliant |
Application Field | Mechanical transmission in chemical, textile machinery, food processing, instrumentation, petroleum and other industries, etc. |
INTERCHANGE
The LILY Bearing part series CGGCNDHJ is a potential replacement for these common bearing part numbers.
LILY
MCMASTER
CGGCNDHJ
