CGGENFID
Price $ 73.88
| Part Number | CGGENFID |
| System of Measurement | Metric |
| Gear Type | Spur |
| Pressure Angle | 20° |
| Component | Gear |
| Bore Type | Round |
| Module | 2 |
| Number Of Teeth | 30 |
| Gear Pitch Diameter | 60 mm |
| OD | 64 mm |
| Face Width | 20 mm |
| Overall Width | 36 mm |
| For Shaft Diameter | 12 mm |
| Material | 303 Stainless Steel |
| Teeth Heat Treatment | Not Hardened |
| Hub Diameter | 50 mm |
| Hub Width | 16 mm |
| RoHS | RoHS 3 (2015/863/EU) Compliant |
| REACH | REACH (EC 1907/2006) (07/08/2021, 219 SVHC) Compliant |
INTERCHANGE
The LILY Bearing part series CGGENFID is a potential replacement for these common bearing part numbers.
LILY
MCMASTER
CGGENFID
