CGJIKGF
Price $ 258.13
| Part Number | CGJIKGF |
| System of Measurement | Inch |
| Shape | Straight |
| Type | Flange, Adapter |
| Material | Alloy 20 Stainless Steel |
| Pressure Class | 150 |
| Fabrication | Forged |
| Connection Type | Pipe |
| Connection Style | Threaded × Flanged |
| Thread Type | NPT |
| Gender | Female |
| Pipe Size | 2 |
| Flanged Connection Surface | Raised |
| Flange OD | 6" |
| For Bolt Diameter | 5/8" |
| Bolt Hole Diameter | 0.75" |
| Bolt Hole Number of | 4 |
| Bolt Circle Diameter | 4 3/4" |
| Maximum Pressure | 290 psi @ 72° F |
| Maximum Steam Pressure | 200 psi @ 360° F |
| For Fitting Class | 150 |
| For Fitting Material | Alloy 20 Stainless Steel |
| For Pipe Schedule | 40 |
| For Pipe Material | Alloy 20 Stainless Steel |
| Specifications Met | ASME B16.5 |
| Weight | 5.255 lbs. |
| RoHS | RoHS 3 (2015/863/EU) Compliant |
| REACH | Not Compliant |
| For Use With | Air, Natural Gas, Oil, Steam, Water |
INTERCHANGE
The LILY Bearing part series CGJIKGF is a potential replacement for these common bearing part numbers.
LILY
MCMASTER
CGJIKGF
