FBHCTFB
Price $ 28.02
| Part Number | FBHCTFB |
| System of Measurement | Inch |
| Gear Type | Spur |
| Pressure Angle | 20° |
| Component | Gear |
| Bore Type | Round |
| Gear Pitch | 10 |
| Number Of Teeth | 15 |
| Gear Pitch Diameter | 1 1/2" |
| OD | 1.7" |
| Face Width | 1 1/4" |
| Overall Width | 1.87" |
| For Shaft Diameter | 3/4" |
| Material | 1117 Carbon Steel |
| Teeth Heat Treatment | Not Hardened |
| Hub Diameter | 1.22" |
| Hub Width | 0.62" |
| RoHS | RoHS 3 (2015/863/EU) Compliant |
| REACH | Not Compliant |
INTERCHANGE
The LILY Bearing part series FBHCTFB is a potential replacement for these common bearing part numbers.
LILY
MCMASTER
FBHCTFB
