FCIHNBB
Price $ 9.85
| Part Number | FCIHNBB |
| System of Measurement | Inch |
| Shape | 90° Elbow |
| Type | Adapter |
| Pressure Class | 150 |
| Connection Type | Pipe |
| Connection Style | Threaded |
| Connection | NPT Female × NPT Male |
| Pipe Size | 1/8 |
| Maximum Pressure | 150 psi @ 72° F |
| Maximum Steam Pressure | 150 psi @ 350° F |
| Material | Galvanized Iron |
| For Pipe Schedule | 40 |
| For Pipe Material | Galvanized Steel |
| For Flange Class | 150 |
| For Flange Material | Galvanized Steel |
| Specifications Met | ASME B1.20.1, ASME B16.3, ASTM A197, UL Listed |
| Features | Acrylic Thread Sealant |
| RoHS | RoHS 3 (2015/863/EU) Compliant |
| REACH | Not Compliant |
| For Use With | Air, Natural Gas, Oil, Steam, Water |
INTERCHANGE
The LILY Bearing part series FCIHNBB is a potential replacement for these common bearing part numbers.
LILY
MCMASTER
FCIHNBB
