FHFEFKFBD
Price $ 52.93
| Part Number | FHFEFKFBD |
| System of Measurement | Inch |
| Gear Type | Worm |
| Component | Gear |
| Bore Type | Round |
| Gear Pitch | 12 |
| Speed Ratio | 20:1 |
| Number Of Teeth | 20 |
| Pressure Angle | 14 1/2° |
| Gear Pitch Diameter | 1.67" |
| For Number Of Thread Starts | 1 |
| OD | 1.85" |
| Face Width | 1/2" |
| Overall Width | 1.125" |
| For Shaft Diameter | 1/2" |
| Material | Cast Iron |
| Hub Diameter | 1.25" |
| Hub Width | 0.625" |
| Hub Material | Cast Iron |
| For Thread Direction | Right Hand |
| Teeth Heat Treatment | Not Hardened |
| Teeth Fabrication | Not Ground |
| RoHS | RoHS 3 (2015/863/EU) Compliant |
| REACH | REACH (EC 1907/2006) (06/10/2022, 224 SVHC) Compliant |
INTERCHANGE
The LILY Bearing part series FHFEFKFBD is a potential replacement for these common bearing part numbers.
LILY
MCMASTER
FHFEFKFBD
