FHFEFKHII
Price $ 29.26
| Part Number | FHFEFKHII |
| System of Measurement | Metric |
| Gear Type | Worm |
| Component | Gear |
| Bore Type | Round |
| Module | 1 |
| Speed Ratio | 80:1 |
| Number Of Teeth | 80 |
| Pressure Angle | 20° |
| Gear Pitch Diameter | 80 mm |
| For Number Of Thread Starts | 1 |
| OD | 83 mm |
| Face Width | 10 mm |
| Overall Width | 20 mm |
| For Shaft Diameter | 10 mm |
| Material | Cast Iron |
| Hub Diameter | 35 mm |
| Hub Width | 10 mm |
| Hub Material | Cast Iron |
| For Thread Direction | Right Hand |
| Teeth Heat Treatment | Not Hardened |
| Teeth Fabrication | Not Ground |
| RoHS | RoHS 3 (2015/863/EU) Compliant |
| REACH | REACH (EC 1907/2006) (07/08/2021, 219 SVHC) Compliant |
INTERCHANGE
The LILY Bearing part series FHFEFKHII is a potential replacement for these common bearing part numbers.
LILY
MCMASTER
FHFEFKHII
