GGECKDE
Price $ 14.98
| Part Number | GGECKDE |
| System of Measurement | Inch |
| Component | Nut |
| Nut Type | Flange |
| Thread Direction | Right Hand |
| Material | Acetal Plastic |
| Flange Material | Acetal Plastic |
| Thread Size | 7/32"-20.8 |
| Length | 1/2" |
| Diameter | 0.406" |
| Flange Width | 3/4" |
| Flange Height | 13/32" |
| Flange Thickness | 1/8" |
| Number of Thread Starts | 1 |
| Thread Type | Rounded Acme |
| Speed Ratio | 1:1 |
| Travel Distance per Turn | 0.048" |
| Number of Mounting Holes | 2 |
| Mounting Hole Diameter | 1/8" |
| Center-to-Center Mounting Hole | 39/64" |
| Hardness | Not Rated |
| Flange Hardness | Not Rated |
| Tensile Strength | Not Rated |
| Dynamic Thrust Load Capacity | 5 lbs. |
| Temperature Range | Not Rated |
| Features | Wear-Compensating Internal O-Ring |
| RoHS | RoHS 3 (2015/863/EU) Compliant |
| REACH | Not Compliant |
| Country of Origin | China |
INTERCHANGE
The LILY Bearing part series GGECKDE is a potential replacement for these common bearing part numbers.
LILY
MCMASTER
GGECKDE
