GIAJFKDGD
Price $ 55.81
| Part Number | GIAJFKDGD |
| System of Measurement | Inch |
| Shape | Straight |
| Type | Flange, Adapter |
| Pressure Class | 150 |
| Connection Type | Pipe |
| Connection Style | Socket Connect × Flanged |
| Socket Connect Type | Weld |
| Socket Depth | 1.06" |
| Flanged Connection Surface | Raised |
| Gender | Female |
| Pipe Size | 6 |
| Flange OD | 11" |
| For Bolt Diameter | 3/4" |
| Bolt Hole Diameter | 7/8" |
| Bolt Hole Number of | 8 |
| Bolt Circle Diameter | 9 1/2" |
| Maximum Pressure | 285 psi @ 72° F |
| Maximum Steam Pressure | 150 psi @ 300° F |
| Material | Steel |
| For Fitting Schedule | 40 |
| For Fitting Material | Iron, Steel |
| For Pipe Schedule | 40 |
| For Pipe Material | Steel |
| Specifications Met | ASTM A105, MSS SP-25 |
| RoHS | RoHS 3 (2015/863/EU) Compliant |
| REACH | REACH (EC 1907/2006) (06/10/2022, 224 SVHC) Compliant |
| For Use With | Air, Natural Gas, Oil, Steam, Water |
INTERCHANGE
The LILY Bearing part series GIAJFKDGD is a potential replacement for these common bearing part numbers.
LILY
MCMASTER
GIAJFKDGD
