GIDCKGG
| Part Number | GIDCKGG |
| System of Measurement | Inch |
| OD | 2.58" |
| Material | Stainless Steel |
| Overall Width | 0.437" |
| Bore Type | Round |
| Gear Type | Spur |
| Gear Pitch | 24 |
| Gear Pitch Diameter | 2.5" |
| Pressure Angle | 20° |
| For Shaft Diameter | 1/4" |
| Hub Diameter | 0.5" |
| Hub Width | 0.25" |
| Number Of Teeth | 60 |
| Teeth Heat Treatment | Not Hardened |
| Set Screw Thread Size | 6-32 |
| Face Width | 3/16" |
| Ro Hs | RoHS 3 (2015/863/EU) Compliant |
| Includes | Set Screw |
| REACH | REACH (EC 1907/2006) (01/16/2020, 205 SVHC) Compliant |
| Component | Gear |
| Heat Treatment | Tooth Surface Induction Hardening |
| Gear Hardness | 45-55HRC |
| Gear Accuracy | ANSI-2 AGMA-11 |
| Application Field | Mechanical transmission in chemical, textile machinery, food processing, instrumentation, petroleum and other industries, etc. |
INTERCHANGE
The LILY Bearing part series GIDCKGG is a potential replacement for these common bearing part numbers.
LILY
MCMASTER
GIDCKGG
