HIIAKDG
Price $ 28.11
| Part Number | HIIAKDG |
| System of Measurement | Inch |
| Gear Type | Spur |
| Pressure Angle | 20° |
| Component | Gear |
| Bore Type | Round |
| Gear Pitch | 32 |
| Number Of Teeth | 48 |
| Gear Pitch Diameter | 1 1/2" |
| OD | 1.56" |
| Face Width | 3/16" |
| Overall Width | 0.438" |
| For Shaft Diameter | 1/4" |
| Material | Brass |
| Hub Diameter | 0.78" |
| Hub Width | 0.25" |
| RoHS | RoHS 3 (2015/863/EU) compliant with exemption 6(c) - Lead in copper alloy |
| REACH | Not Compliant |
INTERCHANGE
The LILY Bearing part series HIIAKDG is a potential replacement for these common bearing part numbers.
LILY
MCMASTER
HIIAKDG
