JBCACABBD
Per Pack Price $ 5.17
Per Pack of 10
| Part Number | JBCACABBD |
| System of Measurement | Metric |
| Material | Zinc-Plated Steel |
| For Screw Size | M22 |
| ID | 22.5 mm |
| OD | 35.9 mm |
| Thickness | 3.8-4.2 mm |
| Washer Type | Split Lock |
| Split Lock Washer Type | Standard |
| Hardness | Rockwell C44 |
| Specifications Met | DIN 127B |
| RoHS | RoHS 3 (2015/863/EU) Compliant |
| REACH | REACH (EC 1907/2006) (01/17/2023, 233 SVHC) Compliant |
| DFARS | Specialty Metals COTS-Exempt |
| Country of Origin | China |
INTERCHANGE
The LILY Bearing part series JBCACABBD is a potential replacement for these common bearing part numbers.
LILY
MCMASTER
JBCACABBD
