KP3L
Price $ 70.00
Number
| Part Number | KP3L |
| Standard Reference | MS27640-3A |
| System of Measurement | Inch |
| Bore Dia | 0.19" |
| Bore Dia Tolerance | -0.0005" to 0" |
| Outer Dia | 0.625" |
| Outer Dia Tolerance | -0.0005" to 0" |
| Ring Width Outer Height | 0.203" |
| Ring Width Outer Height Tolerance | -0.005" to 0" |
| Ring Width Inner Width | 0.245" |
| Ring Width Inner Width Tolerance | -0.005" to 0" |
| Ball Complement No | 10 |
| Ball Complement Dia | 1/8" |
| Ring Shoulder Outer | 0.537" |
| Ring Shoulder Inner | 0.272" |
| Ring Chamfer Outer | 0.01" |
| Ring Chamfer Outer Tolerance | 0" to 0.015" |
| Ring Chamfer Inner | 0.005" |
| Ring Chamfer Inner Tolerance | 0" to 0.015" |
| Radial Internal Clearance | 0.004" to 0.001" |
| Static Radial Load | 1560 lbs |
| Static Thrust Load | 700 lbs |
| Dynamic Radial Ring Inner Load | 1520 lbs |
| Dynamic Radial Ring Outer Load | 1260 lbs |
| Max Starting Torque | 1 oz-in |
| Weight | 0.01 lbs |
