26 0841 01
Part Number | 26 0841 01 |
Brand: LILY | |
Equivalent: ROLLIX |
System of Measurement | Metric |
Series | light profile |
Gear | Without Gear |
Type | Ball |
Bearing Type | Flanged |
Product Type | Slewing Beraing |
Inside Diameter Of Inner Ring | 28.898" |
Outside Diameter Of Outer Ring | 37.323" |
Internal Diameter On Inner Ring | 31.417" |
External Diameter On Outer Ring | 34.803" |
Height Of Overall Bearing Assembly | 2.205" |
Height Of Inner Ring | 1.811" |
Height Of Outer Ring | 1.811" |
Bolt Circle In Inner Ring | 30" |
Bolt Circle In Outer Ring | 36.22" |
Size Holes In Inner Ring | ref. Drawing |
Size Holes In Outer Ring | ref. Drawing |
Number Holes In Inner Ring | 18 |
Number Holes In Outer Ring | 14 |
Ring Material | 42CRO or 50MN |
Ball Materrial | Chrome Steel |
Cage Material | Nylon or 300 Series Stainless Steel |
Seal Material | NBR |
RoHS | Compliant |
Weight | 52 Kg |
INTERCHANGE
The LILY bearing part series 26 0841 01 is a potential replacement for these common bearing part numbers.
LILY
ROLLIX
L26 0841 01
26 0841 01
