JAAEGABCB
![JAAEGABCB High-Strength Steel Hex HeadScrews with Phillips Drive](https://imgl.lily-bearing.com/fastening-and-joining/hex-head-screws/high-strength-steel-hex-headscrews-with-phillips-drive/high_strength_steel_hex_headscrews_with_phillips_drive.png?x-oss-process=image/resize,w_150,h_150,m_pad/auto-orient,1/quality,q_90/format,png)
Per Pack Price $ 6.59
Per Pack of 5
Part Number | JAAEGABCB |
System of Measurement | Inch |
Thread Size | 10-32 |
Length | 1 1/2" |
Threading | Partially Threaded |
Min Thread Length | 1 7/16" |
Head Width | 5/16" |
Head Height | 1/8" |
Drive Size | No. 2 |
Thread Direction | Right Hand |
Screw Size Decimal Equivalent | 0.19" |
Thread Type | UNF |
Thread Fit | Class 3A |
Thread Spacing | Fine |
Head Type | Hex |
Drive Style | External Hex, Phillips |
Material | Steel |
Finish | Cadmium Plated |
Hardness | Rockwell C34 |
Tensile Strength | 160,000 psi |
Specifications Met | NAS1801-3-24 |
RoHS | RoHS 3 (2015/863/EU) Compliant |
REACH | REACH (EC 1907/2006) (07/08/2021, 219 SVHC) Compliant |
Internal Code | 0007 |
INTERCHANGE
The LILY Bearing part series JAAEGABCB is a potential replacement for these common bearing part numbers.
LILY
MCMASTER
JAAEGABCB
