27 0541 01
| Part Number | 27 0541 01 |
Brand: LILY  | |
Equivalent: ROLLIX |
| System of Measurement | Metric |
| Series | light profile |
| Gear | External Gear |
| Type | Ball |
| Bearing Type | Flanged |
| Product Type | Slewing Beraing |
| Inside Diameter Of Inner Ring | 17.087" |
| Outside Diameter Of Outer Ring | 25.197" |
| Internal Diameter On Inner Ring | 19.606" |
| Height Of Overall Bearing Assembly | 2.205" |
| Height Of Inner Ring | 1.811" |
| Height Of Outer Ring | 1.811" |
| Bolt Circle In Inner Ring | 18.189" |
| Bolt Circle In Outer Ring | 23.031" |
| Size Holes In Inner Ring | ref. Drawing |
| Size Holes In Outer Ring | ref. Drawing |
| Number Holes In Inner Ring | 14 |
| Number Holes In Outer Ring | 14 |
| Pitch Diameter Of Gear | 24.803" |
| Module | 6 |
| Number Of Gear Teeth | 105 |
| Tooth Form | Droite |
| Ring Material | 42CRO or 50MN |
| Ball Materrial | Chrome Steel |
| Cage Material | Nylon or 300 Series Stainless Steel |
| Seal Material | NBR |
| RoHS | Compliant |
| Weight | 44 Kg |
})
INTERCHANGE
The LILY bearing part series 27 0541 01 is a potential replacement for these common bearing part numbers.
LILY
ROLLIX
L27 0541 01
27 0541 01
